JUCEG provides high quality YB 12 1600kVA Outdoor Prefabricated Substation,You can rest assured to buy it from our factory.All the equipment is provided as a complete set by JUCEG Manufacturing Factory. Users do not need to purchase any other equipment, which reduces the design workload and construction volume. Compared with conventional civil-type substations, the box-type substations of the same capacity usually occupy only 1/10 to 1/5 of the land area of the conventional substations, significantly saving land resources. The equipment uses high-quality materials and advanced manufacturing processes, and has complete protection functions, such as overcurrent protection, overvoltage protection, and undervoltage protection, which can effectively prevent equipment damage and accidents. The equipment has a compact and reasonable structure, with clear isolation of each functional room, facilitating maintenance and repair. At the same time, YB 12 1600kVA Outdoor Prefabricated Substation has an automatic adjustment function, which can automatically adjust the operating status according to the actual load conditions, improving the reliability and maintainability of the equipment. The equipment design takes into account mobility, allowing it to be easily moved to other locations for use, and is suitable for temporary construction power supply and other scenarios.
|
Code |
Meaning |
|
YB |
Pre-installed (prefabricated) box-type substation |
|
12 |
High-voltage side rated voltage: 12kV |
|
0.4 |
Low-voltage side rated voltage: 0.4kV |
|
1600 |
Transformer rated capacity: 1600kVA |
JUCEG's YB 12 1600kVA Outdoor Prefabricated Substation is precision-engineered for versatility, with baseline specs expandable through customization. Below is a detailed table of key parameters, based on JUCEG Electric's validated testing and compliant with GB/T 17467-1998, IEC 62271-202, and IEEE C37 standards.
|
Parameter |
Value |
|
Rated Voltage (HV/LV) |
12kV / 0.4kV |
|
Rated Capacity |
1600kVA (range: 200–2500kVA available) |
|
Rated Frequency |
50Hz / 60Hz |
|
Connection Group |
Yyn0 or Dyn11 |
|
Impedance Voltage |
4.5%, 6%, or 8% |
|
Tap Range |
±2×2.5% or ±5% |
|
HV Rated Current |
400A, 630A, 1000A, 1250A, 1600A |
|
Short-Circuit Withstand Current |
20kA (3s) / Peak: 50kA |
|
Protection Level |
HV/LV rooms: IP33D; Transformer room: IP23D |
|
Noise Level |
≤50 dB (oil-immersed) |
Application: YB 12 1600kVA Outdoor Prefabricated Substation is applicable to situations where the voltage level is lower than 35 kV. It is also suitable for small unmanned substations with a capacity of 2000 kVA or less. It is applied in urban industrial substations, ring network systems, 35 kV rural power grid substations and other places.
Advantage: Small footprint Easy on-site installation Fast power supply Equipment maintenance is simple No need for dedicated personnel to be on duty Can penetrate deep into the load center
1. Our pricing advantage is obvious and more competitive: direct factory delivery, eliminating the price differences between middlemen and traders.
2. Control over delivery time and quality: production progress, order scheduling, and material usage can all be decided by ourselves; it's convenient to keep in sync with the customer regarding the progress, and the response to after-sales, rework, and rectification is faster.
3. YB 12 1600kVA Outdoor Prefabricated Substation offers customization support: foreign trade customers often need to change dimensions, configurations, and brand placement.
4. You can contact us at any time to inspect the factory, enhancing mutual trust: we can arrange for the customer to inspect the factory and view the production line, and the strength is visible.
1.How are Prefabricated Substation shipped internationally?
Shipped via sea, rail, or truck for global delivery. Prefabricated units in bulk packaging for stability, accessories in wooden cases to withstand transit stresses.
2.Can Prefabricated Substation products be customized?
Yes, tailored for voltage, frequency, and equipment types through JUCEG Electric's engineering team.
3.What warranty do you provide?
At least two years comprehensive coverage for defects, performance, and materials, with extensions available.
4.Is Factory Acceptance Testing (FAT) supported?
Standard: Full electrical, thermal, and integration tests per unit, with client witnessing in-person or remotely.
5.Do you provide after-sales engineering support?
Yes, JUCEG Electric deploys engineers for on-site installation, commissioning, troubleshooting, and audits.
6.Are they suitable for renewables?
Yes, customizable for solar/wind with overload capacity and low noise for grid integration.
